Description
The Eaton DILM65(24V60HZ) XT IEC Contactor is a three-pole non-reversing contactor designed for motor control applications up to 30 kW.
It features a 24 VAC, 60 Hz coil, screw terminals, and a 65 A rated operational current.
With a compact frame D (55 mm) design and compliance to IEC 60947, UL, CSA, and CE standards, this contactor ensures reliable performance for industrial motor control and power switching applications.
Specifications
| Category | Details |
|---|---|
| Manufacturer | Eaton |
| Product Series | XT IEC Contactor |
| Catalog Number | DILM65(24V60HZ) |
| Product Category | Contactors |
| Type | Non-reversing, 3-pole |
| Rated Operational Current | 65 A |
| Coil Voltage | 24 VAC (60 Hz) |
| Frame Size | D (55 mm) |
| Motor Rating | 30 kW |
| Terminal Type | Screw terminals |
| Pole Configuration | 3-pole, 0 NO / 0 NC |
| Application | Motor control (FVNR) |
| Compliance | CE Marked, RoHS Compliant |
| Certifications | CSA Certified, UL Listed, IEC 60947, EN 60947 |
| Dimensions (L × H × W) | 55.88 × 114.3 × 132.08 mm |
| Weight | 0.90 kg |
| Catalog Notes | Screw terminals (6–65A); 5 mm (80–150A); no lugs (185–2000A) |
| Catalog Notes | Screw terminals (6–65A); 5 mm (80–150A); no lugs (185–2000A) |
