Description
The Danfoss VLT® AutomationDrive FC-302 (131B0042) is a high-performance AC frequency converter designed for three-phase 380–500V motor control applications. Encased in a compact IP20 chassis (Frame A3), it features RFI Filter H1 (Class A1/B) for reliable electromagnetic compatibility in industrial environments.
Equipped with a Graphical Local Control Panel (LCP) for intuitive interaction and configuration, this drive is suitable for a wide range of automated systems, especially where user feedback and local control are essential. It is loaded with the latest standard software release, ensuring long-term support and functionality.
Specifications
-
Product Model: FC-302P7K5T5E20H1XGXXXXSXXXXAXBXCXXXXDX
-
Series: VLT® AutomationDrive FC-302
-
Power Rating: 7.5 kW / 10 HP
-
Input Voltage: Three-phase, 380–500 VAC
-
Enclosure: IP20 / Chassis mount
-
RFI Filter: H1 Class A1/B (C1 compliant)
-
Brake Chopper: Not included
-
Control Panel: Graphical Local Control Panel (LCP)
-
PCB Coating: Not coated
-
Fieldbus Option: None
-
Software: Latest standard release
-
Frame Size: A3
-
Continuous Output Current (HO): 14.5–16 A
-
Intermittent Output Current (HO): 23.2–25.6 A
-
Apparent Power (kVA): 11.1
-
Power Loss (Heavy Duty): 225 W
-
Dimensions (HxWxD): 268 × 130 × 205 mm
-
Depth with Option A/B: 220 mm
-
Net Weight: 6.54 kg
-
Gross Weight: 7.546 kg
