Description
The Schneider Electric TeSys GB2CB05 is a 1-pole thermal magnetic circuit breaker designed for efficient protection of industrial control circuits and equipment. With a rated current of 0.5A, it delivers high-performance protection with a breaking capacity of 50kA at 240V and a magnetic trip threshold of 6.6A. The breaker is also suitable for DC loads up to 48V, making it versatile for various control and automation setups.
Thanks to its compact 15mm width, the GB2CB05 easily mounts on DIN rails and operates via a robust toggle lever tested for 8000 cycles. With multi-standard certifications (IEC, UL, CSA) and Green Premium eco-label compliance (RoHS/REACh), this breaker combines safety, efficiency, and sustainability.
Specifications
| Feature | Details |
|---|---|
| Brand | Schneider Electric |
| Product Range | TeSys GB |
| Model Reference | GB2CB05 |
| Product Type | Thermal Magnetic Circuit Breaker |
| Poles | 1P (Single Pole) |
| Rated Current | 0.5 A |
| Rated Voltage (AC) | 250 V (IEC), 277 V (UL) |
| Breaking Capacity (AC) | 50 kA @ 240 V |
| Magnetic Tripping Threshold | 6.6 A (13 × In) |
| Rated Voltage (DC) | Up to 48 V DC-13 |
| Breaking Capacity (DC) | 1.5 kA @ 24 V |
| Control Mechanism | Toggle Lever |
| Mounting Type | 35 mm DIN Rail |
| Width | 15 mm |
| Height | 74 mm |
| Depth | 67 mm |
| Net Weight | 50 g |
| Certifications | IEC, UL, CSA |
| Eco-label | Green Premium (RoHS, REACh compliant) |
| Sales Unit | Sold in packs of 6 |
