Description
The TeSys LRD22 is a reliable thermal overload relay designed for the protection of 3-phase motors up to 11 kW at 400V. With a thermal setting range of 16–24A and tripping class 10A, this relay offers precise motor protection against overloads, phase failures, and load imbalance.
Ideal for use with TeSys D contactors (LC1D25 to LC1D38), it can be directly mounted or separated with the optional LAD7B106 terminal block. Its intuitive design includes a manual/automatic reset selector, test function, fault flag, and 1NO+1NC auxiliary contacts for trip indication.
Certified to global standards (IEC, UL, CSA, CCC, EAC, ATEX, Marine) and compliant with Green Premium (RoHS/REACH), the LRD22 is built for high performance and sustainability in industrial motor control applications.
Specification
| Specification | Details |
|---|---|
| Product Name | Thermal Overload Relay |
| Model Number | LRD22 |
| Thermal Setting Range | 16 – 24 A |
| Tripping Class | Class 10A |
| Rated Operational Voltage | Up to 690 V |
| Motor Protection Capacity | Up to 11 kW @ 400V |
| Reset Modes | Manual / Automatic |
| Test Function | Yes (Simulation of tripping) |
| Auxiliary Contacts | 1 NO + 1 NC for fault signalling |
| Phase Failure Protection | Yes |
| Mounting Options | Direct to LC1D25–D38 or DIN rail/screw |
| Terminal Type | Screw clamp terminals |
| Sealable Cover | Yes (Transparent, lockable) |
| Certifications | IEC, UL, CSA, CCC, EAC, ATEX, Marine |
| Sustainability Compliance | Green Premium (RoHS/REACH) |
| Dimensions (H x W x D) | 66 mm x 45 mm x 70 mm |
| Net Weight | 0.124 kg |
