Description
The SpaceLogic SLA 4-in-1 Air Quality Room Sensor is a versatile multisensor platform designed for seamless integration with Building Automation Systems (BAS). Supporting multiple analog output signals — including 4–20 mA, 0–5 V DC, and 0–10 V DC — it provides reliable compatibility with a wide range of HVAC controllers and environmental monitoring systems.
Encased in a sleek optimum white wall-mounted housing, the sensor features an LCD interface with three control buttons for easy navigation of settings, temperature setpoints, and fan speed adjustments. Integrated sensing elements measure temperature, humidity, carbon dioxide (CO₂), and volatile organic compounds (VOC), delivering comprehensive indoor air quality and humidity monitoring.
Ideal for offices, commercial buildings, healthcare facilities, educational institutions, and hospitality environments, the SpaceLogic Room Unit helps maintain comfortable and healthy indoor spaces while optimizing HVAC performance.
Specifications
| Specification | Details |
|---|---|
| Product Name | SpaceLogic SLA 4-in-1 Air Quality Room Sensor – White (LCD Version) |
| Range | SpaceLogic |
| Product / Component Type | Air quality sensor |
| Measurement Type | Temperature, Humidity, CO₂, VOC |
| Device Application | HVAC |
| Product Specific Application | Indoor air quality control, Humidity control |
| Functions | Temperature control, Fan speed control |
| Output Signal Options | 4–20 mA, 0–5 V DC, 0–10 V DC |
| User Interface | LCD display with 3 control buttons |
| Mounting Type | Wall mount |
| Depth | 23.7 mm (0.9 in) |
| Height | 85 mm (3.3 in) |
| Width | 115 mm (4.5 in) |
| Weight | 0.182 kg |
| Housing Finish | Optimum white |
