Single Row Cam Roller – 361200 R
The SKF 361200 R is a single-row cam roller with a crowned outer surface and seals on both sides. Based on a deep groove ball bearing, it is pre-greased, sealed, and ready to mount, providing long service life and reliable performance in cam drives and conveyors.
Original price was: $19.04.$18.05Current price is: $18.05.
(Save $0.99)
In stock
Description
The SKF 361200 R cam roller is a compact, ready-to-mount bearing designed for cam drives, conveyor systems, and track-based applications. Built on the proven single-row deep groove ball bearing design, it features a thick-walled outer ring with a crowned running surface that ensures smooth operation and proper load distribution.
Sealed on both sides and pre-greased for life, the 361200 R minimizes maintenance while ensuring reliable lubrication and effective protection against contaminants. With its C3 clearance and contact seals, this cam roller provides stable performance and extended bearing life, making it an excellent choice for demanding environments.
Specifications
| Attribute | Value |
|---|---|
| Part Number | 361200 R |
| Type | Single row cam roller |
| Net Weight | 0.0392 kg |
| Bore Diameter (d) | 10 mm |
| Functional Outside Diameter (D) | 32 mm |
| Width (B) | 9 mm ( |
| Basic Dynamic Load Rating (C) | 4.68 kN |
| Basic Static Load Rating (C0) | 2.04 kN |
| Limiting Speed | 12,000 r/min |
| Number of Rows | 1 |
| Rolling Elements | Balls |
| Outer Ring Profile | Crowned |
| Cage | With |
| Radial Internal Clearance | C3 |
| Tolerance Class | Normal (except crown) |
| Sealing | Seal on both sides |
| Sealing Type | Contact |
| Lubricant | Grease (for life) |
| Relubrication Feature | Without |
| Bearing Material | Bearing steel |
| Coating | Without |
| Bearing Part | Complete track roller |
| eClass Code | 23-05-08-01 |
| UNSPSC Code | 31171504 |
Additional information
| Weight | 0.0392 kg |
|---|---|
| Dimensions | 32 × 9 mm |
