Sensor/Actuator cable – DOL-0804-G05M

The DOL-0804-G05M is a durable sensor/actuator cable designed for reliable signal and power transmission in industrial automation applications. It features a straight female M8 4-pin connector on one end and flying leads on the other for flexible integration. With a PVC jacket, nickel-plated brass locking nut, and orange color coding, this cable offers high visibility, durability, and ease of installation in various environments.

Specifications:

• Part Number: DOL-0804-G05M

• Cable Length: 5 m

• Connector A: Female M8, 4-pin, straight

• Connector B: Flying leads

• Connector Material: TPU

• Connector Color: Orange

• Locking Nut Material: CuZn, nickel-plated brass

• Tightening Torque: 0.3 Nm

• Cable Type: 4-wire, unshielded

• Jacket Material: PVC

• Jacket Color: Orange

• Cable Diameter: 5 mm

• Conductor Cross-Section: 0.25 mm²

• Bending Radius (Flexible Use): > 10x cable diameter

• Bending Radius (Stationary): > 5x cable diameter

• Voltage Rating: ≤ 30 V

• Current Rating: 4 A

• Signal Type: Sensor/Actuator
