Photoelectric Switch Fiber Unit – E32-CC200
Omron E32-CC200 photoelectric fiber unit, M6 threaded, diffuse reflective sensing, 2100 mm range, 2 m cable, IP67 protection, with top-view sensing surface.
Original price was: $350.92.$332.57Current price is: $332.57.
(Save $18.35)
In stock
Description
The Omron E32-CC200 Photoelectric Fiber Unit is designed for reliable object detection in compact spaces. Featuring a diffuse reflective sensing method with a maximum sensing distance of 2100 mm, this fiber unit provides precise detection with a small spot lens for enhanced accuracy.
Its M6 threaded shape allows easy mounting in tight applications, while the 2 m polyethylene-sheathed cable ensures durability and flexible installation with a bending radius of 25 mm. With a plastic core construction and IP67 protection, the E32-CC200 is built to withstand harsh industrial environments.
Suitable for a wide range of object detection applications, the fiber unit operates reliably in extreme conditions with an operating temperature range from -40°C to +70°C. The top-view sensing orientation makes it ideal for precise detection in confined or angled setups.
Specifications
| Attribute | Details |
|---|---|
| Product Type | Photoelectric Fiber Unit |
| Sensing Method | Diffuse Reflective |
| Shape | Threaded |
| Size | M6 |
| Application | Object Detection |
| Features | Small spot with lens |
| Sensing Distance | 2100 mm |
| Sensing Surface Orientation | Top-view |
| Cable Length | 2 m |
| Cable Bending Radius | 25 mm |
| Material Core | Plastic |
| Material Sheath | Polyethylene |
| Protection Rating | IP67 |
| Operating Temperature | -40°C to +70°C |
Additional information
| Weight | 0.3 kg |
|---|
