Photoelectric Sensor – WS/WE100-2P4439

The WS/WE100-2P4439 from the W100-2 series is a reliable through-beam photoelectric sensor pair designed for high-performance object detection over long distances. With a maximum sensing range of 33 meters, it is ideal for use in industrial automation, logistics, and packaging lines where uninterrupted detection is crucial.

This sensor emits visible red light for easy alignment and comes with a 270° potentiometer for fine sensitivity adjustment, allowing seamless adaptation to varied operational environments. Despite its powerful detection capabilities, it features a compact housing (11 x 31 x 20 mm), perfect for tight installation spaces.

Engineered for efficiency, the emitter and receiver consume minimal power, making it a dependable and energy-conscious solution for continuous operation.

Specifications

• Device type: Through-beam photoelectric sensor (emitter and receiver)

• Housing design: Rectangular

• Dimensions (W x H x D): 11 mm x 31 mm x 20 mm

• Type of light: Visible red light

• Light source: LED

• Wavelength: 632 nm

• Light spot size (at 12 m): Ø 850 mm

• Adjustment: 270° sensitivity potentiometer

• Supply voltage: 10 V DC to 30 V DC

• Ripple: ±10%

• Average LED service life: 100,000 hours at +25 °C
