Motor Protection Circuit Breaker – 3RV1011-1JA10

The Siemens 3RV1011-1JA10 is a high-performance motor protection circuit breaker from the SIRIUS 3RV1 series, designed to protect motors from overload, short circuit, and phase failure. With an adjustable thermal current range of 7 to 10 A and a magnetic trip point at 130 A, this device is ideal for various industrial motor applications. Built for compact installations, it features a standard switching capacity and screw terminals for easy wiring.

Specifications:

• Article Number: 3RV1011-1JA10

• Net Weight: 0.617 lb (approx. 0.28 kg)

• Dimensions (L x W x H): 1.929 x 3.937 x 3.307 in (49 x 100 x 84 mm approx.)

• Packaging Unit: 1 Piece

• EAN: 4011209263697

• UPC: 754554409047

• Commodity Code: 85362010

• Country of Origin: Germany

• RoHS Compliant: Since 01.01.2013
