Modicon X80 Analog Input Module – BMXAMI0410
Modicon X80 analog input module, 4 high-level isolated inputs, ±10V / 0–20mA / 4–20mA, 16-bit resolution, DIN rail mount.
Original price was: $390.45.$372.46Current price is: $372.46.
(Save $17.99)
In stock
Description
The BMXAMI0410 analog input module is part of the Modicon X80 series, designed for accurate signal acquisition in industrial control systems. Featuring 4 high-level isolated analog inputs with 16-bit resolution, it supports multiple input ranges: ±10V, ±5V, 0–10V, 0–5V, 1–5V, 0–20mA, and 4–20mA—allowing flexible integration with sensors and transmitters across a wide range of industrial applications.
With channel-to-channel isolation, it ensures signal integrity and noise immunity, making it ideal for precision monitoring, process control, and measurement in harsh environments. The module uses a 20-way removable connector and occupies a single slot in the backplane rack. Protected with an IP20-rated casing, it offers reliability and easy installation in automation systems using Modicon PACs.
Specifications
| Attribute | Value |
|---|---|
| Range of Product | Modicon X80 |
| Product Type | Analog input module |
| Part Number | BMXAMI0410 |
| Analog Input Channels | 4 |
| Input Isolation | Isolated (channel-to-channel) |
| Input Type | Current/Voltage |
| Supported Input Ranges | 0–20 mA, 4–20 mA, ±20 mA, 0–5 V, 0–10 V, ±5 V, ±10 V, 1–5 V |
| Resolution | 16 bits |
| Electrical Connection | 20-way removable terminal block |
| Mounting Type | DIN rail (rack-mounted) |
| Slot Occupancy | 1 |
| IP Rating | IP20 |
| Net Weight | 0.143 kg (0.315 lb) |
| Package Dimensions (L×W×H) | 11.7 × 11.1 × 5.6 cm |
Additional information
| Weight | 0.143 kg |
|---|---|
| Dimensions | 11.7 × 111 × 5.6 mm |
