Modicon Premium Analog Input Module – TSXAEY414
Modicon Premium TSXAEY414 analog input module, 4-channel, multirange inputs, 16-bit conversion, thermocouple/resistance/voltage/current sensing.
Original price was: $870.66.$830.56Current price is: $830.56.
(Save $40.10)
In stock
Description
The Modicon Premium TSXAEY414 is a high-performance analog input module designed for use with the Modicon Premium automation platform. It supports 4 low-level analog inputs, offering multirange compatibility with a wide variety of signal types including current (4–20 mA), voltage (±10V, 0–10V, 0–5V, 1–5V, ±5V, 13–63mV), and temperature sensors such as thermocouples (types B, E, J, K, L, N, R, S, T, U) and RTDs (Pt100, Pt1000, Ni1000 – 2/4 wires). It also supports resistance measurements up to 3850 ohms.
With a 16-bit A/D conversion, this module provides high accuracy for industrial monitoring and control applications. Its compact build ensures easy integration into Modicon Premium racks, while maintaining excellent reliability.
Specifications
| Attribute | Value |
|---|---|
| Range of Product | Modicon Premium Automation Platform |
| Product Type | Analog Input Module |
| Part Number | TSXAEY414 |
| Number of Analog Inputs | 4 |
| Input Type | Low level |
| Analog Input Signal Types | – Current: 4–20 mA – Voltage: ±10 V, 0–10 V, 0–5 V, 1–5 V, ±5 V, 13–63 mV |
| – Thermocouple: B, E, J, K, L, N, R, S, T, U | |
| – Resistance: 0–400 Ω, 0–3850 Ω | |
| – Temperature Probes: Pt100, Pt1000, Ni1000 (2 or 4 wires) | |
| Analog/Digital Conversion | 16 bits |
| Net Weight | 0.32 kg |
Additional information
| Weight | 0.32 kg |
|---|---|
| Dimensions | 260 × 180 × 55 mm |
