Miniature Circuit Breaker (MCB) – A9F44432
4-pole 32A MCB with C-curve tripping for effective protection in industrial and commercial applications. Features VisiTrip and VisiSafe indicators. Complies with IEC/EN 60898-1 and 60947-2.
Original price was: $30.65.$29.05Current price is: $29.05.
(Save $1.60)
In stock
Description
The Acti9 iC60N A9F44432 is a high-quality 4-pole miniature circuit breaker (MCB) designed for reliable protection of electrical circuits against short circuits and overloads. Rated at 32A with a C tripping curve, it is ideal for general-purpose loads with moderate inrush currents in residential, commercial, and light industrial installations.
Built for performance and safety, the MCB includes a VisiTrip indicator for easy identification of a faulted circuit and a VisiSafe green strip that ensures safe downstream maintenance by confirming physical contact separation. With compliance to both IEC/EN 60898-1 (6kA) and IEC/EN 60947-2 (10kA), it delivers dependable circuit protection.
The device supports DIN rail mounting, has a robust electrical endurance of 10,000 cycles, and a mechanical life of 20,000 operations. It also includes high short-circuit protection up to 20kA at 240VAC (IEC 60947-2). This compact breaker is ideal for control panels and switchboards, thanks to its durable build and operational reliability.
Specifications
| Attribute | Details |
|---|---|
| Product Name | Miniature Circuit Breaker (MCB) |
| Model | Acti9 iC60N Disbo |
| Reference | A9F44432 |
| Poles | 4P (Four Protected Poles) |
| Rated Current (In) | 32 A |
| Tripping Curve | C Curve |
| Rated Insulation Voltage (Ui) | 500 VAC |
| Breaking Capacity | 10kA (IEC 60947-2), 6kA (IEC 60898-1) |
| Short-Circuit Capacity | Up to 20kA at 240VAC |
| VisiTrip Indicator | Yes |
| VisiSafe Feature | Yes |
| Mounting Type | DIN Rail |
| Width | 72 mm (8 x 9mm pitch) |
| Height | 85 mm |
| Depth | 78.5 mm |
| Net Weight | 0.5 kg |
| Electrical Endurance | 10,000 cycles |
| Mechanical Endurance | 20,000 cycles |
| Degree of Protection | IP20 (device), IP40 (in enclosure) |
| Pollution Degree | 3 |
| Overvoltage Category | IV |
| Operating Temperature Range | -35°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Color | White (RAL9003) |
| Compliance Standards | EN/IEC 60898-1, EN/IEC 60947-2 |
Additional information
| Weight | 0.5 kg |
|---|---|
| Dimensions | 72 × 78.5 × 85 mm |
