Description
The SKF FRB 10/340 locating (stabilizing) ring is a precision-engineered accessory essential for securing bearings in the locating position. Bearings in this position must be fixed axially in the housing, and when dimensional mismatches occur between the bearing seat and housing width, stabilizing rings are used to achieve correct alignment.
Typically, two locating rings are required per housing—one on each side of the bearing—for optimal stability. In applications where only one locating ring is needed, it should be installed on the same side as the lock nut to ensure effective load handling.
Manufactured from high-quality materials, the FRB 10/340 provides reliability, durability, and ease of installation. It is widely used in industrial applications where large bearings are mounted, delivering precise axial positioning that contributes to extended bearing service life.
Specifications
| Attribute | Details |
|---|---|
| Part Number | FRB 10/340 |
| Accessory Type | Locating (stabilizing) ring |
| Inside Diameter | 320 mm |
| Outside Diameter | 340 mm |
| Width | 10 mm |
| Product Net Weight | 0.523 kg |
| eClass Code | 23-05-17-90 |
| UNSPSC Code | 31171519 |
