Description
The 2094-BC02-M02-M Integrated Axis Power Module from Allen-Bradley is a high-performance power solution designed for the Kinetix 6200 multi-axis motion control platform. This Integrated Axis Module (IAM) combines both converter and inverter sections within a single unit, simplifying panel design while delivering reliable power for servo drive applications.
Rated for 400/460 VAC three-phase input, the module provides up to 15 kW converter output to supply downstream axis modules. It supports demanding motion control systems used in packaging, material handling, robotics, and automated production equipment. A separate control module is required for operation.
The unit features efficient thermal performance, compact installation requirements, and robust electrical characteristics, making it suitable for high-density control cabinets. Built to industrial standards, it ensures stable DC bus power distribution and dependable system operation even in continuous-duty environments.
Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen-Bradley |
| Product Line | Kinetix 6200 |
| Part Number | 2094-BC02-M02-M |
| Product Type | Integrated Axis Power Module (IAM) |
| Category | Drives |
| Input Voltage | 400/460 VAC |
| Nominal Drive Voltage | 360–480 V (3-Phase) |
| Converter Section Output | 15 kW |
| Inverter Section Output | 72 W |
| Output Current | 15 A |
| Wattage | 6.6 kW |
| Power Dissipation | 36–75 W |
| Heat Dissipation (Converter) | 44 W at 20% |
| Heat Dissipation (Inverter) | 72 W at 40% |
| Maximum Bus Capacitance | 8955 µF |
| Control Input Fuse | FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) |
| Installation Clearance | 80 mm (3.10 in.) |
| Minimum Enclosure Depth | 302 mm (11.9 in.) |
| Operating Temperature | 0–50 °C (32–122 °F) |
| Control Module Requirement | One (1) required (sold separately) |
| Weight | 13.00 lbs (5.90 kg) |
| UPC | 884951092518 |
