Description
The Schneider Electric ACX-4-000HXAC is a high-capacity access controller from the Continuum series. It supports up to 8 card readers and provides advanced security, encryption, and alarm features in a modular and scalable design. The controller integrates with Ethernet networks and supports expansion for additional I/O. It’s ideal for medium to large access control installations requiring robust performance, secure communication, and future-proof scalability.
Specifications
| Category | Details |
|---|---|
| Product Reference | ACX-4-000HXAC |
| Series | Continuum ACX |
| Type | Ethernet Access Controller |
| Reader Support | Up to 8 readers |
| Encryption | High-level encryption |
| XDriver Support | Yes |
| Advanced Alarming | Yes |
| Critical Security | Yes |
| Power Consumption | ~ 90 VA (AC), ~ 50 W (DC) |
| Dimensions (L × W × H) | 209.6 mm × 241.3 mm × 57.2 mm |
| Weight | ~ 0.78 kg |
| Operating Environment | 0 °C to 50 °C, 10–90% relative humidity (non-condensing) |
| Enclosure Rating | Open class, UL94-5V, IP10 |
| Mounting Method | Wall or panel mounting with screws |
| Communication Interfaces | Ethernet (RJ-45), RS-485 for field bus |
| I/O Expansion | Supports expansion modules for additional inputs/outputs |
| Compatibility | Works with CyberStation, Infinet field bus systems |
| Security Features | Embedded security modules, tamper detection, alarm integration |
