Description
The SKF 6314-2Z/C3 Deep Groove Ball Bearing is a robust, versatile, and long-lasting bearing designed to perform reliably in demanding industrial environments. Featuring double non-contact metal shields, it keeps grease in and contaminants out, ensuring extended service life and dependable performance.
With its SKF Explorer performance class, the 6314-2Z/C3 provides superior load-carrying capacity, optimized running accuracy, and reduced vibration compared to standard bearings. Its design allows it to handle both radial and axial loads in either direction, while its low-friction operation enables higher speeds and lower energy consumption.
Perfect for use in motors, gearboxes, pumps, fans, and other machinery, this bearing combines simple installation with reduced maintenance needs, making it a cost-effective and reliable solution for a wide range of applications.
Specifications
| Category | Details |
|---|---|
| Bearing Type | Deep Groove Ball Bearing (Single Row) |
| Model | 6314-2Z/C3 |
| Performance Class | SKF Explorer |
| Bore Diameter | 70 mm |
| Outside Diameter | 150 mm |
| Width | 35 mm |
| Dynamic Load Rating (C) | 111 kN |
| Static Load Rating (C₀) | 68 kN |
| Reference Speed | 9,500 r/min |
| Limiting Speed | 5,000 r/min |
| Radial Internal Clearance | C3 |
| Sealing | Shields on both sides (Non-contact) |
| Lubrication | Greased, maintenance-free |
| Cage Material | Sheet metal |
| Bore Type | Cylindrical |
| Material | Bearing steel |
| Relubrication Feature | Without |
| Net Weight | 2.58 kg |
| Carbon Footprint (Manufacture) | 9.3 kg CO₂e |
| Classification Codes | eClass: 23-05-08-01 / UNSPSC: 31171504 |
