Deep Groove Ball Bearing – 6017-2RS1
The SKF 6017-2RS1 is a single row deep groove ball bearing. It features contact seals on both sides, supports high-speed rotation, low friction, and accommodates both radial and axial loads, ideal for diverse industrial applications.
Original price was: $53.00.$50.23Current price is: $50.23.
(Save $2.77)
In stock
Description
The SKF 6017-2RS1 deep groove ball bearing is designed for durability and reliability in demanding environments. With contact seals on both sides, it retains grease while preventing contaminants from entering the bearing, ensuring extended service life.
Its single row design and CN radial internal clearance allow smooth operation under varying loads and thermal conditions. Constructed from premium bearing steel with a sheet metal cage, this bearing delivers low maintenance, high-speed capability, and robust performance.
Suitable for use in electric motors, pumps, gearboxes, and other industrial machinery, it combines efficiency with ease of installation.
Specifications
| Attribute | Value |
|---|---|
| Part Number | 6017-2RS1 |
| Bearing Type | Deep groove ball bearing |
| Number of Rows | 1 |
| Bore Diameter | 85 mm |
| Outside Diameter | 130 mm |
| Width | 22 mm |
| Basic Dynamic Load Rating | 52 kN |
| Basic Static Load Rating | 43 kN |
| Reference Speed | 11,000 r/min |
| Limiting Speed | 3,000 r/min |
| Radial Internal Clearance | CN |
| Bore Type | Cylindrical |
| Cage Material | Sheet metal |
| Sealing | Seal on both sides |
| Sealing Type | Contact |
| Lubricant | Grease |
| Relubrication Feature | Without |
| Filling Slots | Without |
| Matched Arrangement | No |
| Locating Feature, Outer Ring | Without |
| Material | Bearing steel |
| Coating | Without |
| SKF Performance Class | SKF Explorer |
| Product Net Weight | 0.924 kg |
| Indicative Carbon Footprint (Manufacture) | 3.33 kg CO2e |
| eClass Code | 23-05-08-01 |
| UNSPSC Code | 31171504 |
Additional information
| Weight | 0.924 kg |
|---|
