Central I/O Module – SXWDI16XX10001
The SXWDI16XX10001 is a SpaceLogic DI-16 I/O expansion module with 16 digital inputs for connection to SpaceLogic AS-P servers. It supports alarm point monitoring, equipment status detection, and energy metering applications, offering hot-swappable installation, auto-addressing, and LED signaling for ease of use.
Original price was: $214.40.$211.84Current price is: $211.84.
(Save $2.56)
Out of stock
Description
The SpaceLogic DI-16 I/O module (SXWDI16XX10001) is a compact and reliable expansion solution designed for integration with SpaceLogic AS-P servers. Featuring 16 digital inputs, this module allows seamless monitoring of equipment status, alarm conditions, and pulse counting applications such as energy metering. Its support for high-frequency digital signals (up to 25 Hz) ensures compatibility with a wide range of building management system requirements.
Installation is simplified through direct connection to the SpaceLogic AS-P server via plug-in terminal bases, eliminating the need for complex wiring. Thanks to its hot-connectable and hot-swappable design, the module supports continuous operation during maintenance or replacement, minimizing system downtime. An auto-addressing feature further reduces engineering and commissioning time, while built-in LED indicators provide clear status feedback for each input channel.
Constructed from durable ABS + PC materials and compliant with UL94V0-5VB flame retardance standards, the module ensures safety and longevity. Certified to CE, FCC, ICES-003, RCM, UL 864, and UL 916 standards, it is suitable for global deployments. The SXWDI16XX10001 is a reliable choice for expanding digital I/O capacity in modern building automation systems powered by EcoStruxure Building Operation.
Specifications
| Specification | Value |
|---|---|
| Part number | SXWDI16XX10001 |
| Range | EcoStruxure Building Operation |
| Product brand | Schneider Electric |
| Product type | I/O module |
| Product name | I/O Modules |
| Device short name | DI-16 |
| Input/output type | 16 × digital input |
| Discrete input voltage | 24 V |
| Switching frequency | 25 Hz |
| Local signalling | Green/Red LED for input status |
| Electrical connection | Plug-in sub-base |
| Mounting support | DIN rail, Wall mounting |
| Range compatibility | EcoStruxure TB-IO-W1 terminal base |
| Control type | Without |
| Communication | Direct connection to SpaceLogic AS-P server |
| Certifications | CE, RCM, ICES-003, FCC part 15 class B |
| Standards | UL 864, UL 916, FCC CFR 47 part 15 |
| Material | ABS + PC |
| Flame retardance | UL94V0-5VB |
| Power consumption | 1.6 W |
| Degree of protection | IP20 |
| Relative humidity | 0…95 % non-condensing |
| Ambient operating temperature | 0…50 °C |
| Ambient storage temperature | -20…70 °C |
| Dimensions (L × H × W) | 64 × 114 × 30 mm |
| Net weight | 0.194 kg |
Additional information
| Weight | 0.194 kg |
|---|---|
| Dimensions | 64 × 30 × 114 mm |
