Ball Valve Actuator – MB3-SO-24F
Compact electric ball valve actuator with 3-wire floating control, spring return open function, and 3 Nm torque. Designed for reliable automation in HVAC and building applications, operating on 24 VAC with IP31 protection.
Original price was: $147.40.$136.22Current price is: $136.22.
(Save $11.18)
Out of stock
Description
The MB3-SO-24F Ball Valve Actuator is a compact and efficient solution for controlling ball valves in HVAC and building management systems. Featuring a secure Pop Top connection, the actuator ensures quick, tool-free installation on compatible valve bodies, minimizing setup time.
This model operates on 24 VAC with three-wire floating control, delivering precise functionality in both commercial and residential environments. Its spring return mechanism opens the valve automatically in case of power loss, ensuring system safety and reliability.
With a torque output of 3 Nm, IP31 protection, and a durable rotary design, the MB3-SO-24F actuator is well-suited for demanding applications. Its clear position indicator and integrated cable gland enhance usability and long-term maintenance efficiency.
Specifications
| Attribute | Detail |
|---|---|
| Product or component type | Actuator |
| Actuator type | Electric |
| Actuator range | MB3 |
| Actuator model | MB3 SRO-24F T31 T3 |
| Application | Ball valves |
| Operation | Rotary |
| Control type | Electrically operated |
| Supply voltage | 24 V AC |
| Transformer rated power | 10 VA |
| Power consumption | 3 W / 3.2 VA AC |
| Return on power loss | Spring return open |
| Control signal | 3-wire floating |
| Torque | 2.9 Nm (26 lb.in) |
| Position indicator | Green push rod with color markers |
| Conduit connection | M20 |
| Cable gland | For 5–9 mm wire OD |
| IP protection rating | IP31 |
| Operating temperature | 0…60 °C |
| Storage temperature | −40…76 °C |
| Relative humidity | 5…95% non-condensing |
| Target regions | Europe, Asia Pacific, Australia |
| Package type | PCE |
| Units per package | 1 |
| Package dimensions | 170 mm x 90 mm x 110 mm |
| Package weight | 470 g |
Additional information
| Weight | 0.49 kg |
|---|---|
| Dimensions | 170 × 90 × 110 mm |
